Assembly Instruction

QUBE 1-SECTION
Made in China - r03 Page 2 of 3
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
2 Insert 4 cams into 1 left and right side panels as
shown. Make sure arrows on each cam point toward
nearest edge with holes.
left and right
side panels
5 Position bottom panel as shown. Fit cam screws of
bottom panel into corresponding holes of right side
panel as shown. Using a phillips head screwdriver,
turn cams clockwise until each cam securely engages
each cam screw. Repeat for left side panel.
right side
panel
3 Attach 1 magnet to top panel with 2 medium screws
as shown, using a phillips head screwdriver. Do not over
tighten the screws.
NOTE: Do not over
tighten the screws
NOTE: Make sure arrows
on each cam point toward
nearest edge with holes
magnet
top
panel
4 Attach 4 feet to bottom panel with 2 large screws per
foot as shown, using a screwdriver.
foot
bottom
panel
bottom
panel
