Assembly Instruction

Made in China - r06 Page 2 of 4
PASSAGES
BOOKCASE
1 Fit dowels of top panel, fixed shelf, and bottom panel
into corresponding holes of right side panel as shown.
Secure with 5 small bolts, 5 spring washers, and 5 flat
washers. Fasten bolts with a phillips head screwdriver.
right side
panel
2 Fit dowels of assembled unit into corresponding holes of
left side panel as shown. Secure with 5 small bolts, 5
spring washers, and 5 flat washers. Fasten bolts with
screwdriver.
flat washer
spring washer
small bolt
3 Fit dowels of assembled unit into corresponding holes
of front frame. Secure front frame with 12 small bolts, 12
spring washer, and 12 flat washers.
4 Fit dowels of legs into corresponding holes of
assembled unit as shown. Secure each leg with 1 large
bolt, 1 spring washer, and 1 flat washer as shown.
top
panel
fixed
shelf
bottom
panel
left
side panel
front
frame
leg
large
bolt
spring washer
flat washer
