Assembly Instruction

ManualsBrandsCrate & Barrel ManualsStorage FurnitureCrate & Barrel Kenton Cube with Shelf

Table Of Contents

Customer Service 800-967-6696 | http://www.crateandbarrel.com

HARDWARE

Thank you for purchasing the Kenton Cube with

Shelf. This page lists all the contents included in the

box. Please take time to identify the hardware as

well as the individual components of this product. As

you unpack and prepare for assembly, place the

contents on a carpeted or padded area to protect

them from damage.

COMPONENTS

TOOLS REQUIRED

Phillips head screwdriver

KENTON CUBE WITH SHELF

Page 1 of 2

Made in China - r04

Missing hardware? Please call

800.606.6387 for replacements.

8 - cam

screws

8 - cams

8 - wood

dowels

1 - back panel

4 - shelf pins

1 A. Insert 4 wood dowels into the inner holes on the

edges of the 2 side panels.

B. Insert 4 cams into the large holes in each side panel.

Make sure arrow on each cam points out towards edge

with dowels.

x 2

2 Insert 4 cam screws into each outer hole of the 2

end panels as shown. Secure each screw with a phillips

head screwdriver, but do not over tighten.

8 - cam covers

x 2

Make sure

arrow on

each cam

points towards

edge with dowels

x 2

1 - shelf

2 - end panels

(1 labeled top,

1 labeled bottom)

2 - side panels

(left labeled L, right

labeled R)

Summary of content (3 pages)

PAGE 1
KENTON CUBE WITH SHELF HARDWARE 8 - cams 8 - cam screws 8 - wood dowels 4 - shelf pins Missing hardware? Please call 800.606.6387 for replacements. 8 - cam covers COMPONENTS Thank you for purchasing the Kenton Cube with Shelf. This page lists all the contents included in the box. Please take time to identify the hardware as well as the individual components of this product. As you unpack and prepare for assembly, place the contents on a carpeted or padded area to protect them from damage.
PAGE 2
KENTON CUBE WITH SHELF B Cam in unlocked position Cam in locked position A 3 A. Place side panels into position as shown, making sure slot on each panel lines up with slot on bottom panel. Align dowels and cam screws and firmly press into position. B. Slide back panel into the corresponding slot in the bottom & side panels. 4 Using a phillips head screwdriver, turn each cam at the base of the side panels clockwise until each cam tightly engages the cam screw. A B 6 A.
PAGE 3
KENTON SINGLE & DOUBLE CUBE ATTACHMENT MULTIPLE CUBE STACKING FOR SINGLE & DOUBLE CUBES TOOLS REQUIRED Phillips head screwdriver HARDWARE INCLUDED Single Cube - 2 wood screws Double Cube - 4 wood screws Single Cube - 1 mending plate Double Cube - 2 mending plates NOTE: Do not stack more than 5 cubes high A B 1 A. Stack cubes in desired configuration, making sure the rear edges of each cube are aligned and flush. B.
