Assembly Instruction

Customer Service 800-967-6696 | http://www.crateandbarrel.com

4 Make any necessary adjustments to align the seat and

the leg frame. Using the allen wrench, fully tighten all 9

screws on the footrest and underside of the seat.

INFINITY 24" & 30" BARSTOOL

Page 2 of 2

Made in Taiwan

2 A. Loosely insert two 1-3/8"L screws and two split

washers through lower leg, through 2 leg mounts and into

seat. Do not fully tighten.

B. Loosely secure legs at center with one 3/4"L screw &

one split washer. Do not fully tighten.

3 A. Fit two footrest caps onto ends of footrest.

B. Align holes in footrest with corresponding holes in the

legs. Loosely attach front of footrest with two 5/8"L screws

and the back with two 1-1/2"L screws. Do not fully tighten.

CLEANING AND CARE

Clean surfaces with a dry or damp soft cloth. Do not use

abrasive cleaners. Do not use furniture wax or polish as the

wood is finished with a protective clear lacquer.

Note: Arrows on

legs point

towards

front of seat

Arrow label

faces forward

x 9

5 Insert 4 feet into the holes on the bottom of the

legs. Assembly is now complete.

Note: Arrows on

legs point

towards

front of seat
