Assembly Instruction

HARDWARE

TOOLS REQUIRED

COMPONENTS

1 With the assistance of another adult, place

tabletop face down onto a clean, padded surface.

Attach each leg to tabletop with 2 bolts, 2 spring

washers and 2 flat washers as shown. Fully

tighten all bolts with an allen wrench. Position

unit upright.

Assembly is now complete.

Made in Vietnam - r05 Page 1 of 2

Thank you for purchasing the Huxley Extension Dining

Table. This page lists all the contents included in the

box. Please take time to identify the hardware as well

as the individual components of this product. As you

unpack and prepare for assembly, place the contents

on a carpeted or padded area to protect them from

damage.

Note: 2 people are required to safely assemble this product.

HUXLEY EXTENSION DINING TABLE

Missing hardware? Please call 800.606.6387 for replacements.

8 - bolts 8 - flat

washers

1 - tabletop 1 - leaf

8 - spring

washers

4 - legs

allen wrench (included)

Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com

bolt

flat

washer

spring

washer

tabletop

leg

PAGE 1
HUXLEY EXTENSION DINING TABLE HARDWARE 8 - bolts 8 - flat washers 8 - spring washers Missing hardware? Please call 800.606.6387 for replacements. TOOLS REQUIRED allen wrench (included) Thank you for purchasing the Huxley Extension Dining Table. This page lists all the contents included in the box. Please take time to identify the hardware as well as the individual components of this product.
PAGE 2
HUXLEY EXTENSION DINING TABLE EXTENSION LEAF INSTALLATION A B 2 A) Locate the 2 metal clasps on the underside of the tabletop. Unlatch each clasp to unlock tabletop as shown. B) With the assistance of another adult, pull 2 tabletop sections apart. Place leaf into position, aligning metal pins on leaf with matching locator holes. Push both tabletops towards the center. EXTENSION LEAF STORAGE 4 Remove leaf by unlocking clasps.
