Assembly Instruction

Customer Service 800-967-6696 | http://www.crateandbarrel.com
Made in Indonesia R03
Page 2 of 3
HAVANA
BUFFET
With assistance of another adult, carefully lay back panel
onto padded surface. Align holes in side panels with
corresponding holes in back panel and insert 8 flat head
bolts and 8 large washers. Do not fully tighten the bolts.
1
2
3
Fit front panel onto assembled unit and insert 8 flat
head bolts and 8 large washers through the side
frames into the front panel. Do not fully tighten the
bolts.
Attach top panel with 6 pan head bolts and 6 large
washers as illustrated. Do not fully tighten bolts.
x 8
x 6
4
Insert 4 flat head bolts and 4 large washers as shown.
At this point, fully tighten all bolts installed in Steps 1-4
with a phillips head screwdriver.
x 4
