Assembly Instruction

Made in China - r07 Page 3 of 3
DELANO SIDEBOARD
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
5 Attach left back panel to assembly with 8 screws,
and right back panel with 13 screws as shown.
Secure, but do not over tighten, with a phillips head
screwdriver.
7 Slide open door and insert 4 shelf pins into each
side at desired shelf heights. Place 2 adjustable
shelves onto shelf pins. Make sure notch of each
shelf is assembled toward corresponding back corner.
6 With the assistance of another adult, position unit
upright as shown. Locate locking mechanism behind
left door (without pull) and unlock as shown. Angle
bottom of left door into bottom back groove of
assembly, and fit top of door into top back groove.
At this point, lock door into place.
Repeat steps for remaining right door (pull
pre-attached) for top and bottom front grooves.
left door
(top and bottom
back groove)
right door
(top and bottom
front groove)
LOCK
UNLOCK
left back
panel
right back
panel
CLEANING & CARE
Clean surfaces with a dry or damp soft cloth. Do not use
abrasive cleaners. Do not use furniture wax or polish as
the unit is finished with a protective clear lacquer.
8 Attach pull to left door with 2 pull screws as
shown, using a screwdriver.
Assembly is now complete.
