HARDWARE

TOOLS REQUIRED

COMPONENTS

1 A) Insert 4 wood dowels into bottom panel as shown.

B) Insert 6 wood dowels into top panel as shown.

Made in China - r07 Page 1 of 3

Thank you for purchasing the Delano Sideboard. This

page lists all the contents included in the box. Please

take time to identify the hardware as well as the

individual components of this product. As you unpack

and prepare for assembly, place the contents on a

carpeted or padded area to protect them from damage.

Note: 2 people are required to safely assemble this product.

DELANO SIDEBOARD

Missing hardware? Please call 800.606.6387 for replacements.

18 - wood

dowels

10 - medium

bolts

2 - small

bolts

4 - large

bolts

2 - bolt

caps

16 - flat

washers

16 - spring

washers

8 - shelf

pins

2 - pull

screws

21 - screws

1 - partition 2 - back panels

(1 left, 1 right)

2 - side panels

(1 left, 1 right)

2 - left and

right doors

(pull pre-attached

to right door)

2 - adjustable

shelves

(1 left, 1 right)

4 - legs 1 - pull

1 - bottom

panel

1 - top

panel

Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com

(We recommend the use of hand tools instead of power tools)

allen wrench (included)

phillips head screwdriver

Summary of content (3 pages)

PAGE 1
DELANO SIDEBOARD HARDWARE 18 - wood dowels 2 - small bolts 4 - large bolts 2 - bolt caps 10 - medium 21 - screws bolts 16 - flat washers 16 - spring washers 2 - pull screws 8 - shelf pins Missing hardware? Please call 800.606.6387 for replacements. Thank you for purchasing the Delano Sideboard. This page lists all the contents included in the box. Please take time to identify the hardware as well as the individual components of this product.
PAGE 2
DELANO SIDEBOARD NOTE: Make sure side panels and partition are oriented as shown during assembly A partition A B B top panel 2 A) Fit dowels of top panel into corresponding holes of left and right side panels as shown. Secure each side panel with 2 medium bolts, 2 spring washers and 2 flat washers, using an allen wrench. Do not over tighten the bolts. B) Attach partition to top panel with 2 small bolts, 2 spring washers and 2 flat washers as shown. B A 3 Insert 2 wood dowels into each leg as shown.
PAGE 3
DELANO SIDEBOARD right door (top and bottom front groove) LOCK left back panel right back panel left door (top and bottom back groove) UNLOCK 5 Attach left back panel to assembly with 8 screws, and right back panel with 13 screws as shown. Secure, but do not over tighten, with a phillips head screwdriver. 6 With the assistance of another adult, position unit upright as shown. Locate locking mechanism behind left door (without pull) and unlock as shown.
