Assembly Instruction

Made in China - r10 Page 3 of 4
BUNGALOW LOW BOOKCASE
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
4 A) Attach 1 partition to assembled unit with 2 short bolts
and 2 flat washers as shown.
B) Attach top panel to side panels of assembled unit with 4
small bolts and 4 flat washers as shown.
C) Attach top panel to partition of assembled unit with 2
medium bolts and 2 flat washers as shown. At this point,
fully tighten all bolts with an allen wrench. With the
assistance of another adult, carefully position unit upright.
Assembly is now complete.
top
panel
CLEANING & CARE
Clean surfaces with a dry or damp soft cloth. Do not use
abrasive cleaners. Do not use furniture wax or polish as the unit
is finished with a protective clear lacquer. It is recommended to
use coasters to protect surface from heat and water.
3 A) Attach 1 notched partition to bottom
panel of assembled unit with 2 short bolts and
2 flat washers as shown. Secure, but do not
fully tighten, bolts with an allen wrench.
B) Attach 1 fixed shelf to assembled unit with
6 medium bolts and 6 flat washers as shown.
Repeat steps A and B for remaining notched
partition and fixed shelf.
fixed
shelf
notched
partition
medium bolt
flat washer
A
B
NOTE: Do not
fully tighten bolts
short bolt
flat washer
A
B
partition
(without notches)
A
B
medium bolt
flat washer
short bolt
flat washer
A
C
C
short bolt
flat washer
B
