Assembly Instruction

Made in China - r10 Page 2 of 4
1 A) Insert 2 wood dowels into left and right
side panels as shown.
B) Insert 5 wood dowels into bottom panel as
shown.
BUNGALOW LOW BOOKCASE
left side
panel
right side
panel
bottom
panel
bottom panel
2 A) Fit dowels of left and right
side panels into corresponding
holes of bottom panel as shown.
At this point, fit dowels of bottom
panel into corresponding holes of
4 feet. Secure each foot with 1
long bolts and 1 flat washers,
using an allen wrench. Do not
fully tighten the bolts.
B) Fit dowel of bottom panel into
corresponding hole of center
support, and secure with 1 long
bolt and 1 flat washer.
foot
center
support
left and right
side panels
center
support
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
long bolt
flat washer
NOTE: Do not fully
tighten the bolts
A
A
B
B
