Assembly Instruction

Customer Service 800-967-6696 | http://www.crateandbarrel.com
BALCONY 5 DRAWER CHEST
Made in Vietnam - r05
Page 3 of 4
5 Fit bottom panel onto assembly as shown. Secure
from below with 6 short screws, 6 split washers and 6
washers. Fully tighten with the screwdriver.
6 Attach 4 legs to underside of bottom panel by inserting
into the threaded holes as shown. Turn each leg clockwise
until secure.
7 A. Attach large right and left drawer sides to large
drawer back with 2 wood screws per side. Do not over
tighten screws.
B. Slide large drawer bottom into groove at the base of the
drawer back and sides.
C. Fit large drawer front onto assembly and secure from the
sides with 4 wood screws.
D. Attach 2 drawer pulls with 2 long screws and 2
washers.
Repeat Steps A-D for remaining 2 large drawers.
8 A. Attach small right and left drawer sides to small
drawer back with 2 wood screws per side. Do not over
tighten screws.
B. Slide small drawer bottom into groove at the base of the
drawer back and sides.
C. Fit small drawer front onto assembly and secure from
the sides with 4 wood screws.
D. Attach 1 drawer pull with 1 long screw and 1 washer.
Repeat Steps A-D for remaining small drawer.
x 6
A
B
C
D
x 3
x 2
Make sure
wheels on drawer
sides are at
the back
Make sure
wheels on drawer
sides are at
the back
