ARM Debugger 166 Support
©1989-2014 Lauterbach GmbH
MXC91231 YES YES YES YES
MXC91321 YES YES YES YES
MXC91323 YES YES YES YES
MXC91331 YES YES YES YES
OMAP2420 YES YES YES YES
OMAP2430 YES YES YES YES
OMAP2431 YES YES YES YES
OMAPV2230 YES YES YES YES
S3C6400 YES YES YES
S3C6410 YES YES YES
SP2603 YES YES YES
SP2606 YES YES YES
SP2612 YES YES YES
SP2704 YES YES YES YES
SP2716 YES YES YES YES
STA2064 YES YES YES YES
STA2065 YES YES YES YES
STA2164 YES YES YES YES
STA2165 YES YES YES YES
CPU
ICE
FIRE
ICD
DEBUG
ICD
MONITOR
ICD
TRACE
POWER
INTEGRATOR
INSTRUCTION
SIMULATOR
