User's Manual

RTM Elster AMCO applicative PFS Coronis Systems
8.APPENDIX B : RTM Elster AMCO Radio commands list
Applicative
command
Direction Description Accessibility
Applicative Command
Parameter field
RTM Elster AMCO Configuration Access
0x0B Host → RTM
Request to read encoder internal
data
Encoder profile only No parameter field
0x8B RTM → Host
Request to read encoder internal
data acknowledgment
Encoder profile only
See Section §5.4.7 for detailed
description
0x0C Host → RTM
Request to detect encoder
model
Encoder profile only No parameter field
0x8C RTM → Host
Request to detect encoder
model acknowledgment
Encoder profile only
See Section §5.4.5 for detailed
description
0x18 Host → RTM
Request to read parameter(s) Pulse and Encoder
See Section §4.2 for detailed
description
0x98 RTM → Host
Request to read parameter(s)
acknowledgment
Pulse and Encoder
See Section §4.2 for detailed
description
0x19 Host → RTM
Request to write parameter(s) Pulse and Encoder
See Section §4.2 for detailed
description
0x99 RTM → Host
Request to write parameter(s)
Acknowledgment
Pulse and Encoder
See Section §4.2 for detailed
description
RTM Elster AMCO Meter Reading Access
0x01 Host → RTM
Request to read current reading Pulse and Encoder No parameter field
0x81 RTM → Host
Request to read current reading
acknowledgment
Pulse and Encoder
See Section §5.5.2 for detailed
description
0x02 Host → RTM
Request to program current register
reading
Pulse profile only
See Section §5.4.1 for detailed
description
0x82 RTM → Host
Request to program current register
reading acknowledgment
Pulse profile only
See Section §5.4.1 for detailed
description
0x03 Host → RTM
Request to read Daily consumption
profile
Pulse and Encoder No parameter field
0x83 RTM → Host
Request to read Daily consumption
profile acknowledgment
Pulse and Encoder
See Section §5.5.3 for detailed
description
0x06 Host → RTM
Request to read TOU buckets Pulse and Encoder No Parameter field
0x86 RTM → Host
Request to read TOU buckets
acknowledgment
Pulse and Encoder
See Section §5.5.5 for detailed
description
0x07 Host → RTM Request to read Datalogging table Pulse and Encoder
See Section §5.5.4 for detailed
description
0x87 RTM → Host
Request to read Datalogging table
acknowledgment
Pulse and Encoder
See Section §5.5.4 for detailed
description
0x0A Host → RTM
Request to configure the route to
use on alarm frame transmission
Pulse and Encoder
See Section §5.12.2 for detailed
description
0x8A RTM → Host
Request to configure the route
acknowledgment
Pulse and Encoder
See Section §5.12.2 for detailed
description
RTM Elster AMCO Miscellaneous commands
0x04 Host → RTM
Request to read leakage event table Pulse and Encoder No parameter field
0x84 RTM → Host
Request to read leakage event table
acknowledgment
Pulse and Encoder
See Section §5.7.4 for detailed
description
0x40 RTM → Host Alarm to indicate default detected Pulse and Encoder
See Section §5.12.3 for detailed
description
0xC0 Host → RTM
Alarm to indicate default detected
acknowledgment
Pulse and Encoder
See Section §5.12.4 for detailed
description
EVO RTM-UserMan 69
