User's Manual

RTM Elster AMCO applicative PFS Coronis Systems
Param
ID
Description
Size
in
bytes
Access
Right
(Pulse
register)
Access
Right
(encoder
register)
Default value
(Hexa)
Restriction
on
parameters
Encoder Unit & Model parameters
0x1D Encoder Model on Port A (encoder only)
2 - R
0xFFFF
0x1E Encoder Model on Port B (encoder only)
2 - R
0xFFFF
0x1F Encoder Unit on Port A (encoder only)
2 - R
0xFFFF
0x20 Encoder Unit on Port B (encoder only)
2 - R
0xFFFF
Leakage detection function
0x21
Residual leakage consumption-rate (low threshold)
on Port A
(The unit is the same as the reading unit)
1 R/W R/W
0x0F
If 0x00 error
0x22
Residual leakage detection period on Port A
(expressed in multiple of 'Reading Sampling
Period')
1 R/W R/W
0xA8
If 0x00 error
0x23
Extreme leakage consumption-rate (high threshold)
on Port A
(The unit is the same as the reading unit)
2 R/W R/W
0x03E8
If 0x0000
error
0x24
Extreme leakage detection period on Port A
expressed in multiple of 'Reading Sampling Period')
1 R/W R/W 0x03 If 0x00 error
0x28
Residual leakage consumption-rate (low threshold)
on Port B
(The unit is the same as the reading unit)
1 R/W R/W
0x0F
If 0x00 error
0x29
Residual leakage detection period on Port B
(expressed in multiple of 'Reading Sampling
Period')
1 R/W R/W
0xA8
If 0x00 error
0x2A
Extreme leakage consumption-rate (high threshold)
on Port B
(The unit is the same as the reading unit)
2 R/W R/W
0x03E8
If 0x0000
error
0x2B
Extreme leakage detection period on Port B
expressed in multiple of 'Reading Sampling Period')
1 R/W R/W 0x03 If 0x00 error
0x30
Residual leakage consumption-rate (low threshold)
on Port C
(The unit is the same as the reading unit)
1 R/W -
0x0F
If 0x00 error
0x31
Residual leakage detection period on Port C
(expressed in multiple of 'Reading Sampling
Period')
1 R/W -
0xA8
If 0x00 error
0x32
Extreme leakage consumption-rate (high threshold)
on Port C
(The unit is the same as the reading unit)
2 R/W -
0x03E8
If 0x0000
error
0x33
Extreme leakage detection period on Port C
expressed in multiple of 'Reading Sampling Period')
1 R/W - 0x03 If 0x00 error
0x38
Residual leakage consumption-rate (low threshold)
on Port D
(The unit is the same as the reading unit)
1 R/W -
0x0F
If 0x00 error
0x39
Residual leakage detection period on Port D
(expressed in multiple of 'Reading Sampling
Period')
1 R/W -
0xA8
If 0x00 error
0x3A
Extreme leakage consumption-rate (high threshold)
on Port D
(The unit is the same as the reading unit)
2 R/W -
0x03E8
If 0x0000
error
0x3B
Extreme leakage detection period on Port D
expressed in multiple of 'Reading Sampling Period')
1 R/W - 0x03 If 0x00 error
EVO RTM-UserMan 66
