User's Manual

RTM Elster AMCO applicative PFS Coronis Systems
7.APPENDIX A : RTM Elster AMCO internal parameters
list
Param
ID
Description
Size
in
bytes
Access
Right
(Pulse
register)
Access
Right
(encoder
register)
Default value
(Hexa)
Restriction
on
parameters
NO ID
Operating Mode 2 R/W R/W
TBD with Elster
AMCO
-
General status
0x01 Application Status 1 R/W R/W
0x00
if no default at start
0x02
Leakage Detection Status 1 R R
0x00
if no default at start
Read only no
limit
Current date
0x04
Current RTC parameter 7 R/W R/W
0x01010101010101
An erroneous
RTC Format
will be
rejected
Profile
0x05
profile parameter 1 R/W R/W
0x02
Between 0x01
and 0x02
Meter Sampling Management
0x07
Reading Sampling Period 1 R/W R/W
0x0B
See section
§4.5.1
0x08
Sampling activation type 1 R/W R/W
0x01 0x01 only
Radio configuration
0x0A
Group number to use in polling mode 1 R/W R/W
0x00
-
0x0B
Group number in Multicast mode 1 R/W R/W
0x00
-
Datalogging feature parameters
0x10
Measurement Period (datalogging in time steps)
expressed in multiple of “Reading Sampling Period”
1 R/W R/W
0x01
-
0x12
Day of the week, or of the month (datalogging) 1 R/W R/W
0x01
Conform day
needed
0x13
Hour of measurement
(datalogging once a week, or once a month)
1 R/W R/W
0x08
Conform hour
needed
0x14
number of records in the datalogging table
(all ports records cumulated)
2 R R
0x0000
Read only
Pulse Register Unit & Model parameters
0x15 Meter Model on Port A (pulse only)
1 R/W -
0x00
0x16 Meter Model on Port B (pulse only)
1 R/W -
0x00
0x17 Meter Model on Port C (pulse only)
1 R/W -
0x00
0x18 Meter Model on Port D (pulse only)
1 R/W -
0x00
0x19 Pulse value on Port A (pulse only)
1 R/W -
0x21
0x1A Pulse value on Port B (pulse only)
1 R/W -
0x21
0x1B Pulse value on Port C (pulse only)
1 R/W -
0x21
0x1C Pulse value on Port D (pulse only)
1 R/W -
0x21
EVO RTM-UserMan 65
