 Alarm Status for RTM Elster AMCO encoder profile
Alarm Status MSB Byte
Bit Number Bit 23
(MSB)
Bit 22 Bit 21 Bit 20 Bit 19 Bit 18 Bit17
Bit 16
(LSB)
Bit Definition
Not used Not used Not used Not used Not used Not used Not used Not used
Alarm Status Middle Byte
Bit Number Bit 15
(MSB)
bit 14 bit 13 bit 12 bit 11 bit 10 bit 9
Bit 8
(LSB)
Bit Definition
Not used
Back flow
detection
on Port B
Back flow
detection
on Port A
Encoder
reading error
detection
on Port B
Encoder
reading error
detection
on Port A
Encoder
communication
error detection
on Port B
Encoder
communication
error detection
on Port A
Low
Battery
Warning
Alarm Status LSB Byte
Bit Number
Bit 7
(MSB)
bit 6 bit 5 bit 4 bit 3 bit 2 bit 1
Bit 0
(LSB)
Bit Definition
Not used Not used Not used Not used
extreme leak
detection
on Port B
residual leak
detection
on Port B
extreme leak
detection
on Port A
residual leak
detection
on Port A
The coding is as follows : 1 : Alarm detected
 Alarm Data Field: the signification of this field depends on the alarm type.
When the alarm is a leakage (extreme or residual) detection, this field corresponds to the consumption-rate
value. When the alarm is a sensor default, this field represents the type of default detected.
Alarm Data Field
Alarm Type MSB byte LSB Byte
High Threshold (Extreme leak) Leak flow value measured
Low threshold (Residual leak) Leak flow value measured
Low Battery Warning current life counter (Parameter 0x50)
Back flow
parameter
“Back flow detection flags”
 Date : Standard RTC format
