5.9.Tamper detection (pulse register only)
Tamper detection is possible if the cable sensor is 3-wire type. In such a case, the 3
rd
wire is connected to a
module input in the same way as the metering input.
Tamper detection is activated by setting bit 4 in the “Operating Mode” parameter.
When Tamper detection is activated, RTM Elster AMCO checks periodically (every second) the state of this
input (0 means no tamper , 1 means tamper). Once a tamper has been detected (input level = 1), RTM Elster
AMCO sets bit 4 in the “Application Status” parameter.
5.9.1.Tamper detection parameters list
Param
ID
Description
Size in
bytes
Access
Right
(Pulse
profile)
Access
Right
(encoder
profile)
Default
value
(Hexa)
Restriction on
parameters
Tamper detection function
0x48 tamper detection date on Port A
7 R -
0x010101
01010101
-
0x49 tamper detection date on Port B 7 R -
0x010101
01010101
-
0x4A tamper detection date on Port C
7 R -
0x010101
01010101
-
0x4B tamper detection date on Port D 7 R -
0x010101
01010101
-
5.9.2.Reading Tamper detection date
 Reading request data format
Applicative
command
Number of
parameters to
read
parameter ID
(Tamper detection date on
Port A)
parameter
length
1 byte 1 byte 1 byte 1 byte
0x18 0x01 0x48 0x07
 Reading acknowledgment data format
The total length is 11 Bytes
Applicative
Acknowledgmen
t command
Number of
parameters
returned
Parameter ID
(Tamper detection date on
Port A)
Parameter
length
Parameter value
1 byte 1 byte 1 byte 1 byte 7 bytes
0x98 0x01 0x48 0x07
