User's Manual

RTM Elster AMCO applicative PFS Coronis Systems
5.8.back flow detection management (encoder only)
5.8.1.back flow detection parameters list
Param
ID
Description
Size in
bytes
Access
Right
(Pulse
profile)
Access
Right
(encoder
profile)
Default
value
(Hexa)
Restriction
on
parameters
Back flow detection function
0x07
Reading Sampling Period 1 R/W R/W
0x0B
See Section
§4.5 for
parameter
description
0x08
Sampling Activation Type 1 R/W R/W
0x01 0x01 only
0x3E Back flow detection date on Port A
7 - R
0x01010101
010101
An erroneous
RTC Format
will be
rejected
0x3F Back flow detection date on Port B 7 - R
0x01010101
010101
An erroneous
RTC Format
will be
rejected
0x40
Back flow detection period on Port A
expressed in multiple of “Reading Sampling Period”
1 - R/W 0x01 If 0x00 error
0x41 back flow detection before indication on Port A
1 R/W
0x02
If 0x00 error
0x42
Back flow threshold on Port A
(same unit as encoder)
1 - R/W
0x0A
If 0x0000
error
0x43
Back flow detection flags on Port A
(rotate every month)
2 - R/W 0x0000 No restriction
0x44
Back flow detection period on Port B
expressed in multiple of “Reading Sampling Period”
1 - R/W
0x01
If 0x00 error
0x45 back flow detection before indication on Port B
1 - R/W
0x02
If 0x00 error
0x46
Back flow threshold on Port B
(same unit as encoder)
1 R/W 0x0A If 0x00 error
0x47
Back flow detection flags on Port B
(rotate every month)
2 - R/W
0x0000
No restriction
 Back flow detection period: this period is a multiple of the “Reading Sampling Period”
parameter. Indicates the water back flow measurement granularity.
 Back flow Threshold : water back flow rate (same unit as encoder).
 Number of back flow presence before detection: this parameter is used to filter the number of
back flow presence before real detection.
 Back flow detection flags : this word contains 12 relevant bits that express back flow detection
in the month.
EVO RTM-UserMan 53
