User's Manual

RTM Elster AMCO applicative PFS Coronis Systems
5.7.3.Leak detection parameters list
Param
ID
Description
Size
in
bytes
Access
Right
(Pulse
register)
Access
Right
(encoder
register)
Default
value
(Hexa)
Restriction
on
parameters
Leakage detection function
0x07
Reading Sampling Period 1 R/W R/W
0x0B
-
0x08 Sampling Activation Type 1 R/W R/W 0x01
Must not
exceed
value 0x01
0x21 Residual leakage consumption-rate (low threshold) on Port A
(The unit is the same as the reading unit)
1 R/W R/W 0x0F If 0x00 error
0x22 Residual leakage detection period on Port A
(expressed in multiple of 'Reading Sampling Period')
1 R/W R/W
0xA8
If 0x00 error
0x23 Extreme leakage consumption-rate (high threshold) on Port A
(The unit is the same as the reading unit)
2 R/W R/W 0x03E8 If 0x0000 error
0x24 Extreme leakage detection period on Port A
expressed in multiple of 'Reading Sampling Period')
1 R/W R/W
0x03
If 0x00 error
0x28 Residual leakage consumption-rate (low threshold) on Port B
(The unit is the same as the reading unit)
1 R/W R/W 0x0F If 0x00 error
0x29 Residual leakage detection period on Port B
(expressed in multiple of 'Reading Sampling Period')
1 R/W R/W
0xA8
If 0x00 error
0x2A Extreme leakage consumption-rate (high threshold) on Port B
(The unit is the same as the reading unit)
2 R/W R/W 0x03E8 If 0x0000 error
0x2B Extreme leakage detection period on Port B
expressed in multiple of 'Reading Sampling Period')
1 R/W R/W
0x03
If 0x00 error
0x30 Residual leakage consumption-rate (low threshold) on Port C
(The unit is the same as the reading unit)
1 R/W - 0x0F If 0x00 error
0x31 Residual leakage detection period on Port C
(expressed in multiple of 'Reading Sampling Period')
1 R/W -
0xA8
If 0x00 error
0x32 Extreme leakage consumption-rate (high threshold) on Port C
(The unit is the same as the reading unit)
2 R/W - 0x03E8 If 0x0000 error
0x33 Extreme leakage detection period on Port C
expressed in multiple of 'Reading Sampling Period')
1 R/W -
0x03
If 0x00 error
0x38 Residual leakage consumption-rate (low threshold) on Port D
(The unit is the same as the reading unit)
1 R/W - 0x0F If 0x00 error
0x39 Residual leakage detection period on Port D
(expressed in multiple of 'Reading Sampling Period')
1 R/W -
0xA8
If 0x00 error
0x3A Extreme leakage consumption-rate (high threshold) on Port D
(The unit is the same as the reading unit)
2 R/W - 0x03E8 If 0x0000 error
0x3B Extreme leakage detection period on Port D
expressed in multiple of 'Reading Sampling Period')
1 R/W -
0x03
If 0x00 error
EVO RTM-UserMan 50
