5.6.3.Example
Daily consumption profile reading is expected on the first RTM installed on the network with the following
parameters:
– Starting hour : 9AM,
– Step time : 5 hours ( means number of transmission per day is not constant),
– Command buffer : Daily consumption profile (applicative command 0x03)
– Cancellation Timeout : 5 seconds (default value)
In this example the current hour is 8.58AM.
Applicative
command
Operating
Mode
Mask on Operating
mode (indicate the
bits that must be
updated)
Number of
param to
write
1
st
param
ID
1
st
param
size
1
st
param
new value
2
nd
param
ID
2
nd
param
size
2
nd
param
new value
0x19 0x0800 0x0800 0x04 0x68 0x03 0x090000 0x69 0x01 0x15
3
rd
param
ID
3
rd
param
size
3
rd
param
new value
4
th
param
ID
4
th
param
size
4
th
param
new value
0x6A 0x07 0x01030000000000 0x6B 0x01 0x05
ATTENTION:
In this case, the first pseudo bubble up transmission will occur at 9AM.
Daily consumption profile reading is also expected on the second RTM installed on the network. The
Wavebox computes a time shift between each RTM pseudo bubble up transmission. In this example the time
shift between the first RTM transmission and the second RTM transmission is 2 minutes.
The second RTM will be configured with the following parameters :
– Starting hour : 9: 02AM,
– Step time : 5 hours ( means number of transmission per day is not constant),
– Command buffer : Daily consumption profile (applicative command 0x03)
– Cancellation Timeout : 5 seconds (default value)
In this example the current hour is 9:04AM.
Applicative
command
Operating
Mode
Mask on Operating
mode (indicate the
bits that must be
updated)
Number of
param to
write
1
st
param
ID
1
st
param
size
1
st
param
new value
2
nd
param
ID
2
nd
param
size
2
nd
param
new value
0x19 0x0800 0x0800 0x04 0x68 0x03 0x090200 0x69 0x01 0x15
3
rd
param
ID
3
rd
param
size
3
rd
param
new value
4
th
param
ID
4
th
param
size
4
th
param
new value
0x6A 0x07 0x01030000000000 0x6B 0x01 0x05
ATTENTION:
In this case, the first pseudo bubble up transmission will occur at 2:02PM. Indeed, the second
RTM computes next pseudo bubble up transmission time in order to respect the time shift that
was defined by the Wavebox between the first RTM and itself. In this case, Starting hour is not
respected since it will induce a time shift of 58 minutes between the first RTM and the second
one.
