User's Manual

RTM Elster AMCO applicative PFS Coronis Systems
5.6.Automatic Radio transmission
(pseudo bubble up mode - Fixed Network Only)
(Refer to DR[3] Section 1.0.20)
RTM Elster AMCO is able to send periodically some of its information through the network. This feature is
fully configurable. Pseudo bubble up like system configuration and activation is made with a single radio
frame.
5.6.1.Pseudo bubble up parameters list
Param
ID
Description
Size in
bytes
Access
Right
(Pulse
Profile)
Access
Right
(encoder
Profile)
Default value
(Hexa)
Restriction on
parameters
Pseudo bubble up feature
0x68
Starting hour, minute and second of the pseudo
bubble up mechanism
3 R/W R/W
0x080000
An erroneous date will
be rejected
0x69
pseudo bubble up transmission period 1 R/W R/W
0x06 See Section §5.6
0x6A
First byte : Data length of bubble up command
buffer
Other bytes : bubble up command buffer (use to
write request command)
7 R/W R/W
0x010300000
00000
The first byte should
not be higher than 6
and the command
should be correctly
written
0x6B
Maximum cancellation Timeout (in seconds): this
time is needed when a process take a too long time
and shift the current RTC compare to the computed
RTC of bubble up emission.
1
R/W R/W
0x05
From 0x01 to 0x0A
pseudo bubble up transmission period defi nition:
step time for automatic transmission (parameter 0x69)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
[b7:b2] : measurement period expressed in time units
min : once a minute
max : every 63 days
[b1:b0] : time unit
00 : 1 minute
01 : 1 hour
1x : 1 day
5.6.2.Pseudo bubble up allowed commands list
Applicative
Command
Command Function
0x01
Current reading
0x03
Daily consumption profile reading
0x06
TOU buckets reading
0x07 Datalogging table reading (rejected in case of multi frame answer)
EVO RTM-UserMan 46
