User's Manual

RTM Elster AMCO applicative PFS Coronis Systems
 Request to read TOU Buckets data format
Applicative command
1 byte
0x06
 Response data format
The total length for 1 port managed is 66 Bytes
The total length for 2 ports managed is 94 Bytes
The total length for 3 ports managed is 122 Bytes
The total length for 4 ports managed is 150 Bytes
Applicative
acknowledgment
command
Generic
Header
RTC on TOU
Buckets mngt
initialization
TOU Buckets
Parameters
Port A
totalizers
(1)
Port B
totalizers
Port C
totalizers
Port D
totalizers
1 byte 23 bytes 7 bytes
7 bytes (1)
28 bytes 28 bytes 28 bytes 28 bytes
0x86
- - - - - - -
(1) Structure of a TOU buckets totalizers:
The total length is 28 bytes
Current
Reading
First TOU buckets
totalizer
2
nd
TOU buckets
totalizer
3
rd
TOU buckets
totalizer
4
rd
TOU buckets
totalizer
5
rd
TOU buckets
totalizer
6
rd
TOU buckets
totalizer
4 bytes 4 bytes 4 bytes 4 bytes 4 bytes 4 bytes 4 bytes
ATTENTION:
If TOU Buckets configuration parameter is modified, it is in charge of the user to initialize the
feature. The only way to reset the TOU buckets totalizers is to modify the TOU buckets activation
bit in Operating Mode parameter.
Each totalizer return by the RTM are complete totalizer means that the current totalizer isn't taken into
account. In other words, at the end of each TOU bucket the current totalizer is stored into a memory and the
user can only access this memory zone through this reading command.
ATTENTION:
When RTM Elster AMCO is configured in Drive By/Walk By mode, TOU buckets are automatically turned
off. So reading TOU Buckets in this case will not be relevant.
EVO RTM-UserMan 45
