5.5.5.Time Of Use (TOU) buckets configuration and readings
RTM Elster AMCO offers the possibility to manage up to 6 TOU buckets. This means that each port has 7
totalizers, one for current reading and the 6 others corresponding to TOU Buckets.
ATTENTION:
Activating TOU Buckets on an unsynchronized RTM is not recommended. Indeed, this feature
highly depends on RTM RTC parameter which is automatically updated only when the RTM is
synchronized.
➔ TOU Buckets configuration
The parametrization can be done by using the standard reading and writing command (See section §4.2).
The parameter to read or write is the parameter 0x60.
Param ID Description
Size
(in bytes)
0x60
TOU buckets configuration parameter
7
Description of the 7 bytes of the TOU buckets parameter:
TOU buckets configuration parameter
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
Number of TOU
buckets
Start hour of the
1
st
TOU bucket
Start hour of the
2
st
TOU bucket
Start hour of the
3
st
TOU bucket
Start hour of the
4
st
TOU bucket
Start hour of the
5
st
TOU bucket
Start hour of the
6
st
TOU bucket
ATTENTION:
RTM Elster AMCO check for coherence in the TOU buckets programming when user access to
the configuration parameter:
– If the number of TOU Buckets is lower than 2, then TOU buckets management will
be rejected (update status = error) even if it is activated.
– If starting hour list is not coherent, i.e. there are windows overlaps, RTM Elster
AMCO sends back to the initiator of the request an error status for parameter
writing access.
– When less than 6 TOU Buckets are expected, fields relative to not used TOU
buckets will not be treated by the RTM Elster AMCO for coherence. Parameter
length is always seven bytes.
