Maximum number of logged reading per Port depending on Frame position:
Frame Position
Number of Ports
configured
maximum logged reading
First Frame
4 Ports
6
3 Ports
8
2 Ports
12
1 Port
24
Following Frames
4 Ports
9
3 Ports
12
2 Ports
18
1 Port
32
ATTENTION:
1) When RTM Elster AMCO is programmed in Fixed Network mode operation and datalogging
reading in pseudo bubble-up is parametrized, it is advised to use the table above to select the
appropriate number of expected logged reading per port. Indeed, if the number of expected
logged reading is too large and so multiframe radio process is used, the behavior of the pseudo
bubble-up mechanism in the whole network will be affected and will lead to a loss of information
coming from th RTM.
2) When RTM Elster AMCO is configured in Drive By / Walk By mode, Datalogging table reading is
limited to the last 36 logs per port.
