User's Manual

RTM Elster AMCO applicative PFS Coronis Systems
(2) format and size of the fields “current readings area”, ”4th, 8th, 12th, 16th, 20th, position logged readings area”
depend on the number of ports managed. The tables below describes the format and the size of these fields.
Pulse profile selected
Number of Ports
Current readings area
( byte order : [Bxx..B0] )
4th, 8th, 12th, 16th, 20th,
position logged readings area
( byte order : [Bxx..B0] )
1
Size : 4 bytes
[B3:B0] : current reading on Port A
Size : 20 bytes
[B19:B0] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port A
2
Size : 8 bytes
[B7:B4] : current reading on Port A
[B3:B0] : current reading on Port B
Size : 40 bytes
[B39:B20] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port A
[B19:B0] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port B
3
Size : 12 bytes
[B11:B8] : current reading on Port A
[B7:B4] : current reading on Port B
[B3:B0] : current reading on Port C
Size : 60 bytes
[B59:B40] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port A
[B39:B20] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port B
[B19:B0] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port C
4
Size : 16 bytes
[B15:B12] : current reading on Port A
[B11:B8] : current reading on Port B
[B7:B4] : current reading on Port C
[B3:B0] : current reading on Port D
Size : 80 bytes
[B79:B60] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port A
[B59:B40] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port B
[B39:B20] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port C
[B19:B0] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port D
Encoder profile selected
Number of Ports
Current readings area
( byte order : [Bxx..B0] )
4th, 8th, 12th, 16th, 20th
position logged readings area
( byte order : [Bxx..B0] )
1
Size : 4 bytes
[B3:B0] : Current reading on Port A
Size : 20 bytes
[B19:B0] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port A
2
Size : 8 bytes
[B7:B4] : Current reading on Port A
[B3:B0] : Current reading on Port B
Size : 40 bytes
[B39:B20] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port A
[B19:B0] : 4th, 8th, 12th, 16th, 20th,
logged readings on Port B
EVO RTM-UserMan 40
