5.5.3.Daily consumption profile reading
Daily consumption profile reading request allows to recover:
➢ generic header,
➢ current readings,
➢ logged readings 4th, 8th, 12th, 16th, and 20th positions in the datalogging table (if
datalogging is set).
ATTENTION:
Daily consumption profile is accurate only when datalogging every hour is programmed.
All other datalogging configuration will not provide daily information using this particular
command.
 Request data format
Applicative command
1 byte
0x03
 Response data format
The total length for 1 Port managed is 62 Bytes
The total length for 2 Ports managed is 86 Bytes
The total length for 3 Ports managed is 110 Bytes
The total length for 4 Ports managed is 134 Bytes
Applicative
acknowledgment
command
Generic
Header
RTC on last
logged
reading
Datalogging
Parameters
Current readings area
4th, 8th, 12th, 16th, 20th,
position logged readings
area
0x83 23 bytes 7 bytes
7 bytes
(See section
§5.2.1 for field
description)
Variable (2) Variable (2)
(1) Datalogging parameters field:
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
Parameter ID 0x07 0x08 0x10 0x12 0x13 0x14
Parameter
description
Reading
Sampling
Period
Sampling
activation type
Measurement
Period
(datalogging in
time steps)
Day of the
week, or of the
month
(datalogging)
Hour of
measurement
(datalogging once
a week, or once a
month)
number of records in the
datalogging table
(all ports records cumulated)
