5.5.2.Current register reading
When current index reading is expected, RTM Elster AMCO sends back through a radio frame the current
readings on each Port connected. If a Port has no meter connected to it, then the corresponding current
reading is set to 0x7FFFFFFF.
Request data format
Applicative command
1 byte
0x01
Response data format (pulse registers connected)
The total length is 40 Bytes
Applicative
acknowledgment
command
Generic
Header
Current reading
Port A
Current reading
Port B
Current reading
Port C
Current reading
Port D
0x81 23 bytes
4 bytes
(MSB first)
4 bytes
(MSB first)
4 bytes
(MSB first) (1)
4 bytes
(MSB first) (1)
Response data format (encoders connected)
The total length is 32 Bytes
Applicative
acknowledgment
command
Generic
Header
Current Reading
on Port A
Current Reading
on Port B
0x81
23 bytes
4 bytes
(MSB first)
4 bytes
(MSB first)
