5.4.7.Reading encoder internal data (Encoder only)
This feature allows to access directly to the information returned by the encoder(s) connected to RTM Elster
AMCO.
ATTENTION:
Data returned could be different according to the encoder model connected.
Reading encoder internal data request data format
Applicative command
1 byte
0x0B
Reading encoder internal data acknowledgment data format
The total length depends on encoder returned data length
Applicative
acknowledgment
command
Encoder
model on
Port A
Encoder
model on
Port B
Size of the
returned data
on Port A
Size of the
returned data
on Port B
Encoder data
different
according to
encoder
connected on
Port A
Encoder data
different
according to
encoder
connected on
Port B
1 byte 2 bytes 2 bytes 1 byte 1 byte N bytes N bytes
0x8B
0xFFFF
if no
encoder
connected
0xFFFF
if no
encoder
connected
0x00
if no encoder
connected
0x00
if no encoder
connected
(*) (*)
(*) Information returned by encoders: if any problem occurred during the communication with the encoder,
then the information returned in the encoder data field is set to 0xFF (N= 1 byte).
Encoder data” returned in case of Elster AMCO encoder connected (N = 29 bytes) :
Information
Size
(in bytes)
Description
AMCO/ELSTER
company identifier
1 0x4B
Value of meter wheels 6 Provide the meter value in ASCII characters
User serial number 10 10 ASCII characters
Registration units code 2 registration units
Encoded wheel digits 1 4,5 or 6 active digits
Digits before decimal point 1
Counted from the first “V” digit ( most significant)
Example: if d=4 & VVVVVV = 654321 then the value = 6573.21
Option 2 Indicates major software version
Manufacture adapter code 2 Example : 0x3730 = “Invision 21C
Error code 2
Checksum 2
