5.4.5.Encoder model detection
(Refers to DR[3] Section 1.0.17; DR[4,5] Section 1.0.16)
RTM Elster AMCO embeds a feature allowing to recognize the encoder model connected.
This feature is performed either when profile selection parameter is programmed with encoder profile value,
or using a dedicated radio command.
RTM Elster AMCO run all encoders drivers and recognizes the connected encoders models.
Once the initialization is completed, RTM Elster AMCO sends back to the command initiator the encoder
model.
Note :
This command has to be performed once the RTM is connected to the encoder, either in the field during
installation phase or during manufacturing phase of the RTM.
 Request data format
Applicative command
1 byte
0x0C
 Response data format
The total length is 7 Bytes
Applicative
acknowledgment
command
Status
Encoder A
Encoder A
model
Status
Encoder B
Encoder B
model
1 byte
1 byte 2 bytes 1 byte 2 byte
0x8C
0x00 = OK
0xFF = sensor error
(1)
0x00 = OK
0xFF = sensor error
(1) : Encoder model description:
Encoder model is 2 bytes long with the MSByte indicating the encoder manufacturer (ELSTER or SENSUS)
and the LSByte indicating the encoder model (example: Scancoder or Invision for Elster AMCO) and this
value takes different meaning depending on the brand.
The table below describes the different encoder models written in field “Encoder model”:
Manufacturer Elster AMCO SENSUS
Encoder
Manufacturer (MSB)
0x01 0x02
Adapter Code (LSB) 0x00 (Scan_Coder)
010 (Dual Scan)
0x2x (Multi Scan)
0x30 (Q100)
0x40 (Scan_Counter)
0x50 (Aqua Master)
0x60 (Invision 11C)
0x70.(Invision 21C)
MANUFACTURER_ID
(First byte of the serial code)
