5.4.RTM-register pairing
5.4.1.Programming current register reading (pulse register only)
This feature allows to initialize the current reading of each Port.
RTM Elster AMCO measures, and count pulses coming from the pulse register. It is thus necessary to
establish the link between the reading of the meter given in volume unit (gallon, for example), and RTM
Elster AMCO current reading accessible through radio link.
Example : if the water meter indicates 1000 gallons.
- if the pulse register is from type k = 1 (1 pulse per gallon)
1000 pulses represent 1000 gallons, so the value to be programmed into the RTM current
reading will be 1000.
- if the pulse register is from type k = 10 (1 pulse per 10 gallons)
100 pulses represent 1000 gallons, so the value to be programmed into the RTM current
reading will be 100.
- if the pulse register is from type k = 100 (1 pulse per 100 gallons)
10 pulses represent 1000 gallons, so the value to be programmed into the RTM current
reading will be 10.
 Request data format
Applicative
command
Writing type
Current
reading A
Current
reading B
Current
reading C
Current
reading D
1 byte 1 byte
4 bytes
(MSB first)
4 bytes
(MSB first)
4 bytes
(MSB first)
4 bytes
(MSB first)
0x02 (*)
(*)Writing type : indicates which current readings have to be written or not.
Writing type byte
b7 b6 b5 b4 b3 b2 b1 b0
Not used Not used Not used Not used
Port D
0: skip
1: write
Port C
0: skip
1: write
Port B
0: skip
1: write
Port A
0: skip
1: write
 Response data format
Applicative
acknowledgment
command
Writing status
1 byte 1 byte
0x82
0x00 : writing OK
0xFF : writing error
