4.3.4.Application Status
“ Application Status” parameter give at any time RTM Elster AMCO fault, or consumption-rate, status.
Each RTM Elster AMCO internal feature that can be activated or deactivated through its corresponding bit in
“Operating Mode” has an associated status bit in “Application status” parameter.
User has to reset each bit by writing the “Application Status” parameter once the default has been handled.
If a fault detection is not handled properly the corresponding bit in “Application Status” parameter will be
set once again.
 RTM Elster AMCO pulse
Application Status (internal parameter ID = 0x01)
Bit Number Bit 7
(MSB)
bit 6 bit 5 bit 4 bit 3 bit 2 bit 1
Bit 0
(LSB)
Bit Definition
Leak detection
(extreme or
residual)
Not used Not used
Tamper
detection on
Port D
Tamper
detection on
Port C
Tamper
detection on
Port B
Tamper
detection on
Port A
Low
Battery
Warning
Pulse profile
X 0 0 X X X X X
The coding is as follows : 0 : not detected
1 : detected
 RTM Elster AMCO encoder
Application Status (internal parameter ID = 0x01)
Bit Number Bit 7
(MSB)
bit 6 bit 5 bit 4 bit 3 bit 2 bit 1
Bit 0
(LSB)
Bit Definition
Leak detection
(extreme or
residual)
Back flow
detection
on Port B
Back flow
detection
on Port A
Encoder
misread
detection on
Port B
Encoder
misread
detection on
Port A
Encoder
communication
fault detection
on Port B
Encoder
communication
fault detection
on Port A
Low
Battery
Warning
encoder profile
X X X X X X X X
The coding is as follows : 0 : not detected
1 : detected
