4.3.3. Alarm Configuration
“Alarm Configuration” parameter is used to enable automatically alarm transmission on fault or other
anomaly independently.
Some internals features can be associated to an alarm configuration bit. To be sure that the Alarm frame will
be sent after fault or problem detection, the user must take care that the corresponding “Operating Mode”
bit is correctly set.
In case of manual network installation, Some other important information have to be configured in RTM
Elster AMCO such as the path to reach the root of the network.
 RTM Elster AMCO pulse
Alarm Configuration (internal parameter ID = 0x58)
Bit Number
Bit 7
(MSB)
bit 6 bit 5 bit 4 bit 3 bit 2 bit 1
Bit 0
(LSB)
Bit Definition
Not used
Not used Not used
Not used
High
threshold
(Extreme
leak)
Low
threshold
(Residual
leak)
Low Battery
Warning
Cut cable
Pulse profile
0 0 0 0 X X X X
0 : alarm frames disabled
1 : alarm frames enabled
 RTM Elster AMCO encoder
Alarm Configuration (internal parameter ID = 0x58)
Bit Number Bit 7
(MSB)
bit 6 bit 5 bit 4 bit 3 bit 2 bit 1
Bit 0
(LSB)
Bit Definition
Not used Not used Back flow
Encoder
misread
High
threshold
(Extreme
leak)
Low
threshold
(Residual
leak)
Low
Battery
Warning
Encoder
communication
failure
Encoder profile
0 0 X X X X X X
0 : alarm frames disabled
1 : alarm frames enabled
ATTENTION :
When RTM Elster AMCO is programmed to send information periodically using Pseudo bubble
up feature, enabling alarm frames is not recommended. Indeed, in such a case alarm frame
management can generate collisions on the radio medium . However, information returned in
pseudo bubble up mode include RTM Elster AMCO Status bytes (Application Status & Leakage
Detection Status) allowing the user software to monitor default detection on the RTM without any
other necessary radio exchange.
