 Writing acknowledgment data format in case of frame format error
Applicative
acknowledgment
command
Operating Mode Status of writing
1 byte 2 bytes 1 byte
0x99
Operating Mode
current value
0x00 --> update Operating Mode OK
0xFF --> Syntax error (not enough bytes in the request)
4.3.Control bytes description
Some internal parameters are very useful to configure RTM Elster AMCO module and verify its state. These
control bytes are:
 Profile selection (1 byte),
 Operating Mode (2 bytes),
 Alarm Configuration (1 byte),
 Application Status (1 byte),
 Leakage detection Status (1 byte),
Depending on the selected profile or the type of connected meter, the meaning of each field could be
different. All these differences are defined below.
4.3.1.Profile selection
Profile selection (internal parameter ID = 0x05)
Value RTM Elster AMCO profile
0x01
1 to 4 Digital Ports
0x02
1 or 2 Encoder Ports
ATTENTION :
RTM Elster AMCO initializes all the features on profile parameter programming. Also, programming the
“Encoder” profile causes an encoder automatic detection.
