Operation Manual

Supported file formats | 647
• Contrast — lets you specify the contrast between the pixels in the image
• Saturation — lets you specify the purity of a color
• Red — lets you specify the amount of red in the image
• Green — lets you specify the amount of green in the image
• Blue — lets you specify the amount of blue in the image
7 From the Resolutions list box, choose an image size.
8 From the Image type list box, choose a color mode.
9 Position the import placement start cursor on the drawing window, and click.

You can also 
Resample a graphic while importing For more information, see “To resample a bitmap while importing”
on page 599.
Crop a graphic while importing For more information, see “To crop a bitmap while importing” on
page 600.
You can drag on the drawing page to resize the image.
You can remove the adjustments made by the photofinisher at the time the original image was scanned and placed on the Photo CD
disk by enabling the Subtract scene balance check box.
You can identify out-of-gamut areas of the image by enabling theShow colors out of gamut check box, which renders the out-of-
gamut pixels in pure red or pure blue.
Kodak Photo CD Image (PCD) technical notes
• Kodak Photo CD (PCD) images may be subject to copyright. The Corel program does not display a warning message about this.
• Other Kodak-compatible programs may install the Kodak pcdlib.dll file in the Windows folder instead of the Windows\System folder.
This difference in the folder location produces an error message.
• When you import Photo CD files, a dialog box appears and prompts you to choose the desired file resolution and color. The resolution is
limited to 72 dpi and the maximum image size is 3072 × 2048 pixels.
• You can import the following color modes: RGB (24-bit), paletted (8-bit), and grayscale (8-bit).
PICT (PCT)
The Macintosh PICT file format was developed for the Mac® OS platform by Apple® Computer Inc. It is a native file format of QuickDraw®
and can contain both vectors and bitmaps. The Macintosh PICT file format is widely used in Macintosh applications.
To import a PICT file
1
Click File Import.
2 Locate the folder in which the file is stored.
3 Choose PCT - Macintosh PICT (*.pct; *.pict) from the list box next to the File name box.
4 Click the filename.
5 Click Import.
6 Click the drawing page.
You can drag on the drawing page to resize the image.
