584 | Corel DESIGNER X7 User Guide
If you click the Equal gutters button, you must specify a value in the Gutter size box.
You can edit the gutters only if you’ve selected an imposition layout with two or more pages across and down.
To adjust margins
1
Click File Print preview.
2
Click the Imposition layout tool .
3 Choose Edit margins from the What to edit list box on the property bar.
4 Click one of the following buttons:
•
Auto margins — sets the margins automatically
•
Equal margins — lets you make the right margin equal to the left one, and the bottom margin equal to the top one
If you click the Equal margins button, you must specify values in the Top/left margin boxes.
When preparing a job for a commercial press, the print service provider may request minimum margin sizes, such as for page
grippers and printers’ marks.
Printing printers’ marks
Printing printers’ marks lets you display information on a page about how a document should be printed.The available printers’ marks are as
follows:
• Crop/fold marks — represent the size of the paper and print at the corners of the page. You can print crop/fold marks to use as guides
to trim the paper. If you print multiple pages per sheet (for example, two rows by two columns), you can choose to print the crop/fold
marks on the outside edge of the page so that all crop/fold marks are removed after the cropping process, or you can choose to add
crop marks around each row and column. Crop/fold marks ensure that marks appear on each plate of a separated CMYK file.
• Bleed limit — determines how far an image can extend beyond the crop marks. When you use a bleed to extend the print job to the
edge of the page, you must set a bleed limit. A bleed requires that the paper you are printing on is larger than the size of paper you
ultimately want, and the print job must extend beyond the edge of the final paper size.
• Registration marks — are required to line up film for proofing or printing plates on a color press. They print on each sheet of a color
separation.
• Color calibration bars — are color scales that print on each sheet of a color separation and ensure accurate color reproduction. To see
calibration bars, make sure that the page size of the print job is larger than the page size of the work you are printing.
• Densitometer scale — is a series of gray boxes ranging from light to dark. These boxes are required to test the density of halftone
images. You can position the densitometer scale anywhere on the page. You can also customize the levels of gray that appear in each of
the seven squares on the densitometer scale.
• Page numbers — helps you collate pages of an image that do not include any page numbers or do not contain page numbers that
correspond to the actual number of pages
• File information — prints file information, such as, the color profile; halftone settings; name, date, and time the image was created;
plate number; and job name
To print crop and fold marks
1
Click File Print.
2 Click the Prepress tab.
3 In the Crop/fold marks area, enable the Crop/fold marks check box.
If you want to print all crop/fold marks, disable the Exterior only check box.
