Operation Manual

Working with pages and layout tools | 489
You can also specify the page size and orientation by clicking View Page sorter view and adjusting the controls on the property bar.
You can also open the Options dialog box with the Page size page displayed by double-clicking the shadow of the drawing page.
To add or delete custom preset page sizes
1
Click Layout Page setup.
The Options dialog box appears with the Page size page displayed.
2 Perform a task from the following table.

To Do the following
Add a custom preset page size Specify a custom page size in the Width and Height boxes, click
the Save button, and type a name for the custom page in the Save
custom page type as box.
The custom preset page size appears in the Size list box.
Delete a preset page size Choose a page size from the Size list box, and click the Delete
button.
With the Pick tool active and no objects selected, you can also add or delete custom preset page sizes by clicking Edit this list at the
bottom of the Page size list box on the property bar.
To choose a layout style
1
Click Layout Page layout.
2 In the Options dialog box, choose a layout style from the Layout list box.
Each layout style is accompanied by a short description and illustration.
To use a label style
1
Click Layout Page setup.
2 In the Document list of categories, click Label, and enable the Labels option.
3 Choose a manufacturer name from the list.
4 Choose the label style you want from the list.
If you want to customize the label style, click Customize label, and adjust the label size, margins, gutters, and the number of labels
appearing on each sheet.
If you want to save the custom label style you created, click the Add button , and type a name for the new label style in the Save as
box.
You cannot use label styles if a drawing contains multiple pages.
For best results, choose Letter paper size and Portrait orientation before applying a label style.
