392 | Corel DESIGNER X7 User Guide
Text cannot be added to the path of another text object.
You can also fit text to a path by clicking the Text tool and pointing to a path. When the pointer changes to the Fit text to path
pointer , click where you want the text to begin, and type.
To fit text to a path
1
Using the Pick tool , select a text object.
2
Click Text Fit text to path.
The pointer changes to the Fit text to path pointer . By moving the pointer over the path, you can preview where the text will be
fitted.
3 Click a path.
If the text is fitted to a closed path, the text is centered along the path. If the text is fitted to an open path, the text flows from the point
of insertion.
Artistic text can be fitted to open or closed paths. Paragraph text can be fitted to open paths only.
Text cannot be fitted to the path of another text object.
To adjust the position of text that is fitted to a path
1
Using the Pick tool , select the text that is fitted to a path.
2 Choose a setting from any of the following list boxes on the property bar:
• Text orientation — specifies how the text bends to follow the path
• Distance from path — distance between the text and the path
• Offset — horizontal position of the text along the path
You can also
Use tick spacing to increase the distance between the path and the
text in specified increments
Select the text. On the property bar, click Tick snapping, enable the
Tick snapping on option, and type a value in the Tick spacing box.
When you move the text from the path, it moves in the increment
you specified in the Tick spacing box. When you move the text, the
distance from the path is displayed below the original text.
Change the horizontal position of fitted text
Using the Shape tool , select the text, and drag the character
nodes that you want to reposition.
Move fitted text along or off the path
Using the Pick tool , drag the red glyph that appears next to
the text.
When you drag the glyph along the path, a preview of the text
is displayed. When you drag the glyph off the path, the distance
between the text preview and the path is displayed.
