Using lenses with objects | 371
Lens Description
Invert Lets you change the colors beneath the lens to their
complementary CMYK colors. Complementary colors are colors that
are opposite each other on the color wheel.
Magnify Lets you magnify an area on an object by an amount that you
specify. The magnify lens overrides the original object’s fill, making
the object look transparent.
Tinted grayscale Lets you change the colors of object areas beneath the lens to
their grayscale equivalents. Tinted grayscale lenses are particularly
effective for creating sepia-tone effects.
Transparency Lets you make an object look like a piece of tinted film or colored
glass
Wireframe Lets you display the object area beneath the lens with the outline or
fill color of your choice. For example, if you set red for the outline
and blue for the fill, all areas beneath the lens appear to have red
outlines and blue fills.
To apply a lens
1 Select an object.
2
Click Effects Lens.
3 Choose a lens type from the list box in the Lens docker.
4 Specify the settings you want.
You cannot apply the lens effect directly to linked groups such as contoured objects, beveled objects, extruded objects, paragraph
text or objects created with Linear pattern tools.
You can preview the different types of lenses in real time without auto-applying them to a drawing by clicking the Lock button and
then choosing a lens and settings to preview. When you find the lens you want to use, click Apply, or click the Lock button again to
resume auto-applying the lenses while previewing them.
To copy a lens
1 Select the object to which you want to copy the lens.
2
Click Effects Copy effect Lens from.
3 Click the object from which you want to copy the lens.
Editing lenses
You can edit a lens to change how it affects the area beneath it. For example, you can change the viewpoint of a lens, indicated by an X in
the drawing window, to display any part of a drawing. The viewpoint represents the center point of what is being viewed through the lens.
