348 | Corel DESIGNER X7 User Guide
•
Use object fill — applies the object’s fill to the extrusion
•
Use solid color — applies a solid color to the extrusion
•
Use color shading — applies a gradient fill to the extrusion
You can apply an unbroken pattern or texture fill to an object by enabling the Drape fills check box before you click the Use object
fill button.
To apply beveled edges to an extrusion
1
In the toolbox, click the Extrude tool .
2 Select an extruded object.
3
Click the Extrusion bevels button on the property bar.
4 Enable the Use bevel check box.
5 Type a value in the Bevel depth box.
6 Type a value in the Bevel angle box.
You can also set the bevel depth and angle by using the Bevel interactive display box below the Use bevel check box.
You can show only the bevel and hide the extrusion by enabling the Show bevel only check box.
To add light to an extrusion
1 Select an extruded object.
2
Click the Extrusion lighting button on the property bar.
3
Click any of the three Light buttons .
The lights appear as numbered circles in the preview window.
4 Drag the numbered circles in the Light intensity preview window to position the lights.
If you want to create more realistic shading, enable the Use full color range check box.

You can also 
Adjust the intensity of a light source Select a light in the Light intensity preview window, and move the
Intensity slider.
Remove a light source Click an active Light button.
To change the vanishing point of an extrusion

To Do the following
Lock a vanishing point Double-click an extruded object. Choose VP locked to object or VP
locked to page from the Vanishing point properties list box on
the property bar.
