346 | Corel DESIGNER X7 User Guide
Extruded fills
You can apply fills to an entire extrusion or only to the extruded surfaces. You can cover each surface individually with the fill, or you can
drape the fill so that it blankets the entire object with no breaks to the pattern or texture.
Left to right: a simple shape, the shape with an extruded fill of solid
color, the shape with an extruded gradient fill and a rotation applied.
Lighting
You can enhance extrusions by applying light sources. You can add up to three light sources to project toward the extruded object with
varying intensity. When you no longer need light sources, you can remove them.
Vanishing points
You can create a vector extrusion in which the lines of the extrusion converge at a vanishing point. The vanishing point of a vector extrusion
can be copied to another object so that both objects appear to recede toward the same point.
You can also give extrusions different vanishing points.
Extrusions with different vanishing points
To create an extrusion
1
Select an object using the Pick tool .
2
Click the Interactive tools button, and click the Extrude tool .
3 Choose a preset from the Presets list box on the property bar.
4 Choose an extrusion type from the Extrusion type list box on the property bar.
If you want to reset the extrusion, press Esc before releasing the mouse button.
