Operation Manual

314 | Corel DESIGNER X7 User Guide
To apply a PostScript fill
1 Select an object.
2
Click Edit  Property manager.
3
In the Property manager docker, click the flyout arrow on the Two-color pattern fill button , and click the PostScript fill button
to display postscript fill options.
4 Choose a fill from the PostScript fill textures list box.
If you want to change the fill properties, click the Edit fill button , and specify the settings you want.
You can also apply a PostScript fill by clicking the Interactive fill tool , clicking the PostScript fill button on the property bar, and
choosing a fill from the PostScript fill textures list box.
Applying mesh fills
When you fill an object with a mesh fill, you can create unique effects. For example, you can create smooth color transitions in any direction
without having to create blends or contours. When you apply a mesh fill, you specify the number of columns and rows in the grid, and you
specify the grid’s intersecting points. After you have created a mesh object, you can edit the mesh fill grid by adding and removing nodes or
intersections. You can also remove the mesh.
A mesh fill can be applied only to closed objects or a single path. If you want to apply a mesh fill to a complex object, you must first create a
mesh-filled object and combine it with the complex object to form a PowerClip object. For more information about working with PowerClip
objects, see “Creating PowerClip objects” on page 185.
You can add color to a patch of a mesh fill and to the individual intersection nodes. You can also choose to mix colors for a more blended
appearance.
In addition, you can smooth the color in a mesh fill to reduce the appearance of hard edges. You can also reveal objects underneath a
selected area by applying transparency to the mesh fill.
To apply a mesh to an object
1 Select an object.
2
In the toolbox, click the Mesh fill tool .
3 Type the number of columns in the top portion of the Grid size box on the property bar.
4 Type the number of rows in the bottom portion of the Grid size box on the property bar, and press Enter.
5 Adjust the grid nodes on the object.

You can also 
Add a node or an intersection Click once within a grid, and click the Add intersection button
on the property bar.
You can also add a node or an intersection by double-clicking
within a grid.
