308 | Corel DESIGNER X7 User Guide
10 Type a value in the Spacing box to set the distance between two instances of the line.
The distance between lines is set from the path for the line, not the edge of the outline. If the Outline width value is high and the
Spacing value is low, the lines might overlap.
11 Repeat steps 5 through 10 for each line you want to edit.
12 Click OK to return to the Hatch fill dialog box, choose a library from the Library list box, and click Add to library.

You can also 
Add lines
Click the Add button . When you add a new line, it is created
directly over the previous line. Change the y-Origin value to view
the new line.
Delete lines In the Hatch lines list, choose a line, and click the Delete button
.
Hide or show lines in the Hatch preview window
In the Hatch lines list, click the Eye icon to the left of the line
name. When the eye appears closed, the line is hidden. When the
eye appears open, the line is displayed.
To scale or transform a hatch fill with an object
1 Select an object.
2
Click Edit Property manager.
3
In the Property manager docker, click the Hatch fill button to display hatch fill options.
4
Click the Hatch fill properties button .
5 In the Edit fill dialog box, enable the following options:
• Transform fill with object — automatically transforms the hatch fill to reflect all future transformations applied to the object
• Scale line width with object — automatically scales hatch lines when the object is resized
To align hatch fills across multiple objects
1 Select two or more objects that have the same hatch fill.
2
On the property bar, click the Fill button , and choose Hatch fill dialog.
3 Enable the Use world coordinates option.
Applying pattern fills
You can fill objects with vector or bitmap pattern fills, as well as two-color fills.
A two-color pattern fill is composed only of the two colors that you choose. A vector pattern fill is a more complex vector graphic composed
of lines and fills. A vector fill can have color or transparent background. A bitmap pattern fill is a bitmap image whose complexity is
determined by its size, image resolution, and bit depth.
Corel DESIGNER provides a collection of vector and bitmap patterns that you can access. You can browse the available patterns, search
patterns by keyword, mark patterns as favorites, vote for patterns that you like, or copy patterns from the Content Exchange to your
personal library. For more information, see “Managing fills and transparencies” on page 319.
