When dragging most vector objects to the palette, you add all object colors to the palette. When dragging a bitmap, you can specify
the number of colors that you want to be added to the palette. If an object includes a fountain fill, texture fill, or pattern fill, only
colors that are defined during the fill creation are supported. Colors from PostScript fills are not supported.
To create a color palette from an object
1 Select an object.
2
Click Window Color palettes Create palette from selection.
3 Type a filename in the File name box.
4 Click Save.
To create a color palette from a document
1
Click Window Color palettes Create palette from document.
2 Type a filename in the File name box.
3 Click Save.
To edit a custom color palette
1
Click Window Color palettes Palette editor.
2 Choose a palette from the list box.
3 Perform a task from the following table.

To Do the following
Add a color Click Add color. In the Select color dialog box, click the Models
tab, click a color in the color selection area, and click Add to
palette.
Treat a color as a spot color In the Selected color area of the Palette editor dialog box, choose
Spot from the Treat as list.
Treat a color as a process color In the Selected color area of the Palette editor dialog box, choose
Process from the Treat as list.
Change a color In the color selection area, click a color, and click Edit color. In the
Select color dialog box, click the Models tab, and click a new color
in the color selection area.
Delete a color In the color selection area, click a color, and click Delete color.
Sort colors Click Sort colors, and choose a color sorting method.
Move a color Drag a color swatch to a new position.
