Operation Manual

252 | Corel DESIGNER X7 User Guide
To adjust the object-export preview
1
Click File Export for  Web.
2 Perform one or more tasks from the following table.

To Do the following
View the bitmap in a single preview frame
Click the Full preview button on the View toolbar.
View two versions of the bitmap in side-by-side frames
Click the Two vertical previews button .
View the two versions of the bitmap with one frame placed above
the other
Click the Two horizontal previews button .
View four versions of the bitmap in separate frames
Click the Four previews button .
Fit a bitmap in the preview window
Click the Zoom to fit button .
Display each pixel in the image data to a single pixel on-screen
Click the Zoom 1:1 pixel button .
Display a bitmap at its actual size
Click the Zoom to actual size button .
Pan to another area of the bitmap
Using the Pan tool , drag the image until the area you want to
see is visible.
Zoom in and out
Using the Zoom in tool or Zoom out tool , click in the
preview window.
Change the display options for the object in a preview frame Click a frame, then choose different export settings from the export
settings area.
To export a web-compatible bitmap
1
Click File Export for  Web.
2 In the Export for web dialog box, choose preset settings from the Preset list box in the upper-right corner of the dialog box.
If you want modify the preset settings, you can change the exporting options in the dialog box.
3 Click Save as.
4 Choose the drive and folder where you want to save the file.
5 Type a name in the File name box.
6 Click Save.

