Operation Manual

Working with objects | 223
You can also 
Specify two points for the angle by dragging In the Transformations docker, click the Rotation angle button
next to the Angle of rotation box, and drag in the drawing
window.
Specify a point on the drawing to rotate around by clicking
In the Transformations docker, click the Specify point button
next to the X and Y boxes, and click a point on the drawing.
Rotate around a point on the selected object In the Center area of the Transformations docker, enable the
Relative center check box, and click the point on the origin locator
that corresponds to the center of rotation that you want to
set.
Adjust the object orientation when rotating In the Transformations docker, enable the Rotate orientation
option .
Keep the object orientation when rotating In the Transformations docker, enable the Retain orientation
option .
Leave the original object unchanged and apply the transformation
to a copy
In the Transformations docker, type a number in the Copies box.
You can also rotate a selected object by dragging a rotation handle clockwise or counterclockwise.
You can also rotate an object by typing a value in the Angle of rotation box on the Transform toolbar. To display the Transform
toolbar, click View Toolbars Transform.
Mirroring objects
With Corel DESIGNER, you can create mirror images of objects. Mirroring an object flips it from left to right or top to bottom. By default, the
anchor point is in the center of the object.
To mirror an object
1 Select an object.
2
Click Object Transformations Scale and mirror.
3
In the Transformations docker, enable the Mirror horizontallyoption or the Mirror vertically option .
4
In the Transformations docker, click the point on the origin locator that corresponds to the point on the object about which you
want to mirror the object.
To leave the original object unchanged and apply the transformation to a copy, type 1 in the Copiesbox in the Transformations docker.
5 Click Apply.
