To create or edit a drawing profile
1
If the Projected axes docker is hidden, click Window Projected axes to display it.
If you want to edit a drawing profile, choose a profile from the list.
2 In the Projected axes docker, do one of the following:
• Enter a value between -360 and 360 in the X axis angle box. Repeat for the y and z axes.
•
Click the User specified angle button next to the Angle box, and drag the pointer in the drawing window.
3 Enter a value between 10 and 500 in the X axis scale box. Repeat for the y and z axes.
4
Click the Save button .
5 Choose where you want to save the file, and type a filename in the Filename box.
6 Click Save.
You can create a custom axonometric drawing profile by having the application calculate the scale values automatically. To do this,
type values in the X axis angle, Y axis angle, and Z axis angle boxes, and enable the Auto axonometric check box. Note that the
Auto axonometric check box may be disabled for some angle values. In such cases, you first need to adjust the angle values so that
the option becomes available.
To delete a drawing profile
1 In the Projected axes docker, choose a drawing profile from the list box.
2
Click the Delete button .

