Operation Manual

Working with lines, outlines, and brushstrokes | 153
If the spraylist that you want is not listed, click the Browse button on the property bar and navigate to the folder where the file is
located.
4 Drag to draw the line.

You can also 
Adjust the number of objects sprayed at each spacing point Type a number in the upper portion of the Images per dab and
image spacing box on the property bar.
Adjust the spacing between dabs Type a number in the lower portion of the Images per dab and
image spacing box on the property bar.
Set the spray order Choose a spray order from the Spray order list box on the property
bar.
Adjust the size of spray objects Type a number in the upper portion of the Size of sprayed objects
box on the property bar.
Increase or decrease the size of the objects to be sprayed as they
progress along the line
Type a number in the lower portion of the Size of sprayed objects
box on the property bar.
Reset a spraylist to its saved settings
Click the Reset values button on the property bar.
Apply transformations to stroke thickness when scaling
Click the Scale stroke with object button on the property bar.
Hide the bounding box for drawing
Click the Bounding box button on the property bar.
Increasing the value for the size of the objects to be sprayed along the line causes objects to become larger as they are distributed
along the path.
Spraylists that have more complex objects use more system resources. Lines that contain complex objects take longer to produce, and
these objects increase the file size. Using symbols for each group in the list can help reduce file size and the demands on your system.
For more information about creating symbols, see “Working with symbols” on page 239.
To rotate the objects to be sprayed
1 Select a spraylist.
2
Click the Rotation button on the property bar.
3 Type a value between zero and 360 in the Angle of rotation box.
If you want each object in the spraylist to rotate incrementally, enable theIncrement check box, and type a value in the box.
4 Enable one of the following options:
• Relative to path— rotates objects in relation to the line
• Relative to page — rotates objects in relation to the page
5 Press Enter.
