148 | Corel DESIGNER X7 User Guide
2
On the property bar, click the Outline pen button .
If you want the start and end arrowheads to have the same size, offset, rotation angle, and orientation, enable the Share attributes
check box in the Arrowheads area of the Outline pen dialog box.
3 In the Arrowheads area of the Outline pen dialog box, click Options below the Start arrowhead or End arrowhead picker, and click
Attributes.
4 In the Arrowhead attributes dialog box, perform any of the tasks in the following table.

To Do the following
Specify the size of an arrowhead In the Size area, type a value in the Length or Width box.
If you want to create a nonproportional arrowhead, disable the
Proportional check box.
Offset an arrowhead In the Offset area, type values in the X and Y boxes.
Mirror an arrowhead In the Mirror area, enable the Horizontally or Vertically check box.
Rotate an arrowhead Specify an angle in the Rotation box.
Save custom arrowhead attributes as an arrowhead preset Enable the Save as arrowheadpreset check box.
You can access the new arrowhead preset from the Start
arrowhead and End arrowhead pickers on the property bar.
Specifying the attributes of an arrowhead does not change the arrowhead preset that was applied.
To edit an arrowhead preset
1
Using the Pick tool , select an object that has an arrowhead.
2
On the property bar, click the Outline pen button .
3 In the Arrowheads area of the Outline pen dialog box, click Options, and choose Edit.
4 In the Arrowhead attributes dialog box, specify the attributes you want.
For information about the attributes you can specify, see “To specify the arrowhead attributes of a line or curve” on page 147.
You can create an arrowhead preset that is based on an existing preset. In the Arrowheads area of the Outline pen dialog box, click
Options, and choose New. Then, specify the attributes you want in the Arrowhead attributes dialog box, and type a preset name in
the Save arrowhead area.
To delete an arrowhead preset, select the preset from the Start or End arrowhead picker in the Outline pen dialog box, click
Options, and choose Delete.
To create an arrowhead preset from an object
1 Select an object to use as an arrowhead.
2
Click Tools Create Arrowhead.
3 In the Create arrowhead dialog box, type a value in the Length box or Width box.
