1 Detergent dispenser drawer
Symbols
Prewash
Wash
Fabric softener
Bleach
2 Mains-on light
It comes on when the machine starts operating and
goes out at the end of the programme.
3 Spin speed selector dial
The spin speed can be selected from 800 rpm to
300 rpm.
The intermediate spin speed on the dial refer to
cottons, synthetics, delicates and wool.
Position 800 corresponds to 750 rpm for synthetics,
delicates and wool:
= no spin.
4 On/Off button (MARCHA/PARADA)
Press this button to start the machine. The same but-
ton is used to switch the machine off.
Before selecting a programme or changing an
ongoing programme the machine must be switched off
by depressing the On/Off button.
5 Half load button (MEDIA CARGA)
Select this button to reduce water consumption on the
rinse cycle when washing a smaller load of cottons or
linens. (Maximum load size = 2.25 kg).
6 Anti-crease button (STOP CON AGUA)
Use only with “gentle” programmes.
The last rinse water is not emptied out, so as to avoid
creasing if the laundry is not removed from the machi-
ne immediately after washing.
The water can be emptied out by pressing the button
again (emptying will be followed by a short spin) or by
selecting the drain programme .
If the button is not pressed, the programmes end with
a short spin.
7 Temperature selector dial (thermostat)
To select the washing temperature turn the dial to the
required value.
When your laundry is only lightly soiled, a cold wash
can be used (dial to position ).
8 Programme selector dial
To select the required washing programme turn the
dial clockwise.
P0519S
1
2
34
5
6
7
8
STOP
CON AGUA
MEDIA
CARGA
MARCHA
MARCHA
PARADA
30°
40°
50°
60°
70°
80°
90°
LC 2850
Blanco muy sucio + prelav. 60°-90°
Blanco sucio sin prelav. 60°-90°
Lana 40°
Colores delicados 30°-40°
Colores
delicados
30°- 40°
Ciclo breve 30°- 40°
Sucio sin prelav. 30°- 60°
Muy sucio + prelav. 30°-60°
82796
SUPREMA
A
L
G
O
D
O
N
L
IN
O
TEMPERATURAS
SINTETICOS MIXTOS L A NA
Use
Control panel
