Specifications Sheet

Deadbolt Specications & Options
ANSI / BHMA Exceeds ANSI Grade-3
Escutcheon
Face Height
4.0”
Cylinder KW1 5-pin std., “C” optional.
Keying
As specied: Available Master keyed,
Builder keyed, KD, KA.
Latch
Adjustable backset, 1” round corner
narrow faceplate std. Square corner or
drive-in adjustable optional.
Strike
PT-DS16 and PT-DS26: Round corner
strikes std. Others available.
Door Prep
Edge bore 1”, latch mortise 1”x 2-1/4”,
cross bore 2-1/8”, backset standard
2-3/8”, optional 2-3/4”.
Door
Thickness
Min 1-3/4”, Max 1-3/4”.
Handing Non-handed
UL Labeled Available 20-minute UL Labeled.
Warranty 2 year mechanical, 5 year nish.
In Stock
Finishes
Case
Qty
SS TB PS AB AN BC PB
Units
DBF x x x
12
DBH x x x
12
Copper Creek Hardware
DB(F/H) 3400 Series ANSI Grade-3
Electronic Keypad Deadbolt Specications
Function Operation
3410
Single Cylinder
Keypad Deadbolt
Lock or unlock deadbolt with key
or interior turn-piece. Alternatively
unlock from outside by entering cor-
rect code.
Available UL
LISTED
Meets ADA
Regulations
Elegant proles with illuminated keypads.
Easy to program.
Use up to 10 individual pass codes and 1 Master/pro-
gramming code.
Replaces any standard deadbolt. Easy to install.
Vacation Mode.
Auto lock feature (10-99 seconds)
Uses 4 standard AA batteries to operate electric latch
motor (not included).
2 year mechanical and 5 year nish warranty
A
B
C
D
A B C D
DBF 6-3/4” 1-1/2” 1.0” 4.0”
DBH 6-3/4” 1-1/2” 1.0” 4.0”
DBH
Single Cylinder
Deadbolt
DBF
Single Cylinder
Deadbolt
